Easy Smart Configuration Utility

User Guide

On this page, you can configure and view the information of the trunk group of the switch.

Choose the menu Switching→Port Trunk to load the following page.

Figure 4-3 Trunk Config

Here you can configure and view the port parameters.

¾ Trunk Config

Trunk ID: Select an identified number for the trunk group from the

drop-down list.

Port: Select the port as the trunk group member. It is multi-optional.

Available ports of trunk1 are port1-port4, and available ports of

trunk2 are port5-port8. Clearing all the ports of the trunk group

will delete this trunk group.

¾ Trunk Table

Select:

Select the desired Trunk. It is multi-optional.

Trunk ID:

Displays the Trunk number here.

Ports:

Displays the Trunk member ports.

SelectAll: Select all the Trunks.

Delete: Delete the selected Trunk.
