Easy Smart Configuration Utility

User Guide

Chapter Introduction

Chapter 3 System This module is used to configure system properties of the

switch. Here mainly introduces:

z System Info: View device information and define the device

description.

z IP Setting: Get and modify the network parameters of the

switch.

z User Account: Modify the username and password for

users to login the Web management page.

z Backup and Restore: Save the current configuration file to

your computer or download a backup configuration file to

your switch.

z System Reboot: Reboot your switch.

z System Reset: Reset the switch to the default.

z Firmware Upgrade: Update the firmware of the switch.

Chapter 4 Switching

This module is used to configure the basic functions of the

switch.

z Port Setting: Configure and view the basic parameters of

each port, including the port status, speed, duplex mode

and flow control.

z IGMP Snooping: Enable IGMP snooping feature and view

the current IGMP Group information.

z Port Trunk: Configure and view the information of the trunk

group of the switch.

Chapter 5 Monitoring This module is used to monitor the traffic information of the

switch, and provide the convenient method to locate and solve

the network problem.

z Port Statistics: View the statistic information of each port.

z Port Mirror: Monitor and mirror network traffic by forwarding

copies of incoming and outgoing packets from one/multiple

ports (mirrored port) to a specific port (mirroring port).

z Cable Test: Diagnose the connection status of the cable

connected to the switch and the distance to the problem

location.

z Loop Prevention: Detect loops using loopback detection

packets, and then display an alert or further block the

corresponding port.
