Tenda n150 [6/81] Back panel
![Tenda n301 [6/81] Back panel](/views2/1190864/page6/bg6.png)
11N Broadband Wireless Router
.
2
◈ Back Panel
Back LED Overview:
Port
Function Description
WAN
Usually for connecting DSL MODEM CABLE
MODEM ISP to the Internet.
1/2/3
Usually for connecting computers, switches .etc.
WPS/ RST
When you press this button for 7 seconds, files set by the
router will be deleted and restored to default factory; for
1 second, WPS will be enabled and the WPS LED will be
blinking accordingly.
PWR
The power adapter is connected and you can use the
provided adapter to supply power.
