Tenda n150 [8/81] Physical installation
![Tenda n301 [8/81] Physical installation](/views2/1190864/page8/bg8.png)
11N Broadband Wireless Router
.
4
1.2 Physical installation
1. Connect one end of the included power adapter to the device and plug the
other end into a wall outlet nearby.(Using a power adapter with a different
voltage rating than the one included with the device will cause damage to the
device)
2. Connect one of the LAN ports on the Device to the NIC port on your PC
using an Ethernet cable.
3. Connect the Ethernet cable from Internet side to the WAN port on the device.
If it is connected to the telephone line, please link the telephone line to the
MODEM and connect the MODEM to the WAN port on the device.
4. When connected, log in to Web manager to set up Internet connection.
