KS-6812 series Technical Manual 2 - 3
LED COLOR
l Type: blue/orange dual color (blue for power on; orange for stand by)
l Indication coverage: system ON/OFF status, external power status
AUDIO AMPLIFIER
l Output audio power 2.0 W (mono signal to internal speaker in back cover)
EXTERIOR
l 12” MINI SIMPLE BASE MODEL DIMENSIONS:
LCD @ 20°: 310 mm (W) x 262 mm (D) x 288 mm (H) or
12.2” x 10.3” x 11.3”
LCD @ 90°: 310 mm (W) x 281 mm (D) x 200 mm (H) or
12.2” x 11.1” x 7.9”
PACKING: 448 mm (W) x 378 mm (D) x 302 mm (H) or
17.6” x 14.9” x 11.9”
l WEIGHT: 4.05 kg (8.9 lbs) GW6.0kg (13.2 lbs)
ENVIRONMENTAL
l TEMPERATURE RANGE:
Operating: 0°C ~ +40°C or 32°F ~ 104°F
Non-operating: -20°C ~ +60°C or -4°F ~ +140°F
l HUMIDITY RANGE:
Operating: 20%RH ~ 80%RH, non-condensing,
max. wet bulb 26°C (78.8°F)
Non-operating: 10%RH ~ 80%RH, non-condensing,
max. wet bulb 28.9°C (84.0°F)
ACCESSORIES
l COM1 terminator plug: 1 pc
l User’s manual: 1 copy
l Power adapter 12 V DC 4.2 A plus power cord
l Product Information CD or Recovery CD or DVD of preloaded OS
