KS-6812 series Technical Manual 2 - 6
l Fingerprint sensor
1. Optical type
2. Detection area : 14.6 x 18.1 mm (nominal at center)
3. Gray scale : 8 bits (256 levels)
4. Resolution : 512 dpi (average x, y over the field)
WIRELESS LAN
l IEEE 802.11b/g with USB interface
COM3 CONVERSION CABLE
l 10 pin RJ45 type modular plug to COM3 port on KS system, DB9
male connector to accept cable from RS232 device.
l This cable can be purchased through the distributor under P/N
21863233801 or refer to page 4-4 of this manual for pin
assignment and wire connection.
PARALLEL PORT ADAPTOR CABLE
l 2 x 10 pin head receptor to reserved parallel port in service
window, DB25 female connector to accept cable from parallel
device.
l This cable can be purchased through the distributor under P/N
21862033420 or refer to page 4-5 of this manual for pin
assignment and wire connection.
PRINTER:
l PP-2000
1. 2-station receipt/journal/validation printer
2. Dot matrix 9 pin
3. Bi-directional printing
4. Auto cutter provides full cut and partial cut
5. Auto-detect between RS232 and EPP interface
