KS-6812 series Technical Manual 2 - 5
CF READER KIT IN MAIN UNIT
l Occupies HDD bay in main unit (standard HDD in main unit is not
installable when this option is installed)
l Accepts CF cards type II 128 MB ~ 1 GB
l Operates as IDE channel 1 master device
2.5” HDD KIT IN BASE
l 80 GB or above
l Ultra SATA II
DRAM EXPANSION
l DDR2 533 SODIMM in 2 sockets up to total 2 GB max. (default
DRAM installed on M/B component side, vacant socket on M/B
solder side under HDD cover for user extension)
l Verified supported memory types:
Technology
Width
Banks
Maximum SODIMM size Maximum Total Capacity
256 Mb X8 4 512 MB 1 GB
256 Mb X16 4 256 MB 512 MB
512 Mb X8 4 1 GB 2 GB
512 Mb X16 4 512 MB 1 GB
1 Gb X8 8 2 GB 2 GB
1 Gb X16 8 1 GB 2 GB
l No support for Fast Chip Select mode
SIDE MOUNT UPGRADE KIT (SD-680)
l USB interface in proprietary internal connector
l Includes MSR and option fingerprint sensor
l MSR
1. ISO 2 tracks (track 1 + track 2) or ISO 3 tracks (track 1 + track 2
+ track 3) or JIS I/II
2. Characteristic parameters of ISO readers can be set via software
3. AAMVA/CA DMV format supported in ISO 3 tracks model
