TA400/800 User Manual
26/64
DID Field
Where to get the DID in SIP packet.
180 Ringing
It is set when the telecom provider needs. Usually
it is not needed.
Remote Party ID
Whether to send Remote-Party-ID on SIP header
or not. Default: no.
Allow Guest
Whether to allow anonymous registration
extension or not. Default: no. It’s recommended
that it is disabled for security reason.
Pedantic
Enable pedantic parameter. Default: no.
Alwaysauthreject
If enabled, when TA FXS Gateway rejects
―Register‖ or ―Invite‖ packets, TA FXS Gateway
always respond the packets using ―SIP404 NOT
FOUND‖. It’s recommended that it is enabled for
security reason.
OPTIONS Response 200
If set to yes, the response to an OPTIONS is
always 200OK.
Session-timers
Enable session-timer mode, default: yes. If you find
the call is cut off every 15 minutes every time,
please disable this.
Session-expires
The max refresh interval
Session-minse
The min refresh interval, which mustn't be shorter
than 90s.
Session-refresher
Choose the session-refresher, the default is Uas.
IAX Settings
IAX is the Internal Asterisk Exchange protocol, you can connect to TA FXS Gateway
or register IAX trunk to another IAX server. It’s supported by the asterisk-based
IPPBX.
Figure 5-10 IAX Settings
Table 5-8 Description of IAX Settings
Items
Description
UDP Port
Port used for IAX2 registrations. Default is 4569.
Bandwidth
Low/medium/high with this option you can control which
