TA400/800 User Manual
39/64
Secondary DNS
Set the secondary DNS for TA400/800.
IP Address2
Set the second IP Address for TA400/800.
Subnet Mask2
Set the second subnet mask for TA400/800.
Figure 9-2 DHCP Mode
Select DHCP mode to get network automatically from the local network.
Figure 9-3 PPPoE
Fill in user name and password to access the Internet via PPPoE.
Service
The administrator can manage all the access methods on TA on the "Service" page.
Figure 9-4 Service Settings
Table 9-2 Description of Service Settings
Items
Description
SSH
By using SSH, you can log in to TA400/800 and run commands.
It's disabled by default. We don't recommend enabling it if not
needed.
The default port for SSH is 8022.
FTP
FTP access;
The default port is 21.
HTTP
HTTP web access;
The default port is 80.
