6
then press the
"
START/STOP
"
button to begin measurement. All offline
measurements will be uploaded to the App automatically upon the next
successful Bluetooth connection.
For detailed operating instructions, please visit www.ihealthlabs.com
.
Note: Physical activity including eating, drinking, and smoking as well as excitement,
stress, and many other factors influence blood pressure results.
ATTENTION: You can stop the measurement process at any time by pressing and
holding the "START/STOP" button for 2 seconds.
SPECIFICATIONS
1. Product name: Wireless Blood Pressure Wrist Monitor
2. Model: BP7
3. Classification: Internally powered;Type BF applied part;IPX0, No AP or
APG;Continuous operation
4. Machine size: approx.2.8"×2.9"×0.7"(72mm×74mm×17.6mm)
5. Cuff circumference: 5.3"- 8.7"(13.5cm-22cm), one size only
6. Weight: approx. 3.7oz(106g)(including cuff)
7. Measuring method: Oscillometric method, automatic inflation and
measurement
8. Memory volume: 120 times with time and date stamp (off-line measurement
only)
9. Power: DC:5.0V 1.0A, Battery: 1*3.7V Li-ion 400mAh
10.Measurement range:
Cuff pressure: 0-300 mmHg
Systolic: 60-260 mmHg
Diastolic: 40-199 mmHg
Pulse rate: 40-180 beats/minute
11.Accuracy:
Pressure: ±3 mmHg
Pulse r ate: ±5%
12.Wireless communication:
Bluetooth V3.0 + EDR Class 2 SPP
Frequency Band: 2.402-2.480 GHz
13.Environmental temperature for operation: 5℃～40℃(41℉～104℉)
14.Environmental humidity for operation: ≤90%RH
15.Environmental temperature for s torage and transport:
-20
℃～
55
℃
(-4
℉～
131
℉
)
16.Environmental humidity for storage and transport: ≤90%RH
17.Environmental pressure: 80kPa-105kPa
18.Battery life: more than 80 measurements on a full charge
19.The blood pressure measurement system includes accessories: pump, valve,
cuff, and sensor.
Note: These specifications are subject to change without notice.
