Ihealth bp7 [8/16] Battery handling and usage
![Ihealth bp7 [8/16] Battery handling and usage](/views2/1192584/page8/bg8.png)
8
range specified in part SPECIFICATIONS, the app will immediately display a
technical alarm on screen. In this case, consult a physician or ensure that
proper measurement procedures are followed. The technical alarm is preset
in the factory and cannot be adjusted or inactivated. This technical alarm is
assigned as low priority according to IEC 60601-1-8.The technical alarm is
non-latching and does not need to be reset.
12.A medical AC adapter w ith an output of DC 5.0V and complies with IEC
60601-1/UL 60601-1 and IEC 60601-1-2/EN 60601-1-2 is suitable for this
monitor, such as ASP5-05010002JU (input: 100-240V, 50/60Hz, 200mA;
output: DC 5.0V, 1.0A). Please note that the monitor jack size is USB mini B.
This Wireless Blood Pressure Wrist Monitor is designed for adults and should never
be used on infants, young children, pregnant or pre-eclamptic patients. Consult your
physician before use on children.
This product might not meet its performance specifications if stored or used
outside the specified temperature and humidity ranges.
Please do not share the cuff with any infectious person to avoid cross-infection.
BATTERY HANDLING AND USAGE
• When the monito
r
is connected to an iOS device, the battery volume will be
displayed on the iOS device. If the power is less than 25%, please charge the
battery. The monitor will not work until the battery has enough power.
•
When you charge t he monitor, the LED will display with different colors
indicating the charging status. See the table below for details.
• When charging is needed, please connect the monito
r
to a powe
r
source. The
monitor can work normally while charging.
•
It is suggested that you charge the battery when the battery is less than 25%.
Overcharging the battery may reduce its lifetime.
Do not change the battery. If the battery can no longer be charged, please contact
Customer Service.
Overcharging the battery may reduce its lifetime.
Lithium battery replacement by inadequately trained personnel could result in a
hazard such as a fire or explosion.
Do not plug or unplug the power cord into the electrical outlet with wet hands.
If the AC adapter is abno rmal, please change the adapter.
Do not pull out the adapter when you are using the monitor.
Do not use any other type of AC adapter as it may harm the monitor.
Monitor Status Status Indicator
Charging Flashing green light
Fully charged Steady green light
Low battery Flashing red light (for a few seconds)
Abnormal state Steady red light
