TA Series Installation Guide
5/17
2. Hardware Specifications
2.1 Overview
Figure 2-1 TA Series Analog VoIP Gateways
Table 2-1 Yeastar TA Telephony Interfaces
Models
Telephony Interfaces
RJ11 FXS Ports
RJ11 FXO Ports
RJ21 FXS Ports
TA400
4
–
–
TA410
–
4
–
TA800
8
–
–
TA810
–
8
–
TA1600
16
–
1
TA1610
–
16
1
TA2400
24
–
1
TA3200
32
–
2
