TA Series Installation Guide
8/17
Table 2-2 LED Indications
LED
Indication
Status
Description
POWER
Power status
On
The power is switched on.
Off
The power is switched off.
RUN
status
Blinking
is running properly.
Not
Blinking/Off
goes wrong.
1-32
FXS Ports
Status
Green light
Solid green: the port is idle.
Green light blinking: there is an ongoing
call on the port.
1-8
FXO Ports
Status
Table 2-3 Ports Descriptions
Ports
Description
Ethernet Port
provides 1 10/100 adaptive RJ45 Ethernet ports, marked as
LAN.
-LAN port: LAN port is for the connection to Local Area
Network (LAN).
Reset Button
Press the reset button to restore the factory defaults.
Please make sure that you want to reset, because once
reset the previous configurations would be erased
automatically.
Power Inlet
For connection of power supply.
RJ11 FXS Ports
For connection of analog phones/fax machines.
RJ11 FXO Ports
For connection of PSTN interfaces or PBX extension
interfaces.
RJ21 FXS Ports
For connection of analog phones/fax machines with an RJ21
to RJ11 cable.
RS232 Console Port
(TA1600/1610/2400/
3200)
For debugging.
2.3 Specifications and Operating Environment
Table 2-4 TA400/410/800/810 Specifications and Operating Environment
TA400/410/800/810
Description
Size (L×W×H)
200 mm × 137 mm × 25 mm
Power Supply
12V 1A
Operating Temperature
0 to 40°C, 32 to 104°F
Storage Temperature
-20 to 65°C, 4 to 149°F
Humidity
10%~90% (Non-condensing)
