TA Series Installation Guide
7/17
Rear Panels
Figure 2-4 TA800 Rear Panel
Figure 2-5 TA3200 Rear Panel
Protective Earth
RJ21 FXS Ports
RUN
CONSOLE
Power Switch
Power Inlet
RESET
POWER
LAN Port
Power Inlet
RESET
LAN Port
WAN Port (reserved)
FXS Ports
FXO Ports for TA410/810
