Dispensing Fluid and Operation Mode Screens
312865T 21
Manual Dispense (FIG. 19)
All Meters
See F
IG. 19 for terms D - H
D. Information Banner: Configurable information
banner. Data is input on Setup Mode Banner Screen,
page 19.
E. Unit of Measurement: Identifies unit of
measurement, pint, quart, gallon or liter. Measurement
Unit is set on Setup Mode Units/Limits Screen, page
15.
F. Home Icon: Returns user to Home Screen.
G. Reset: Resets counter (H) to zero.
H. Counter: Before dispense has begun, display reads
0.00. As fluid is dispensed, counts up from zero.
To reset counter to zero after a dispense:
1. Use the LEFT or RIGHT ARROW button to move
curser to RESET (G).
2. Press center ENTER button. The displayed amount
in field H returns to zero.
To dispense in Manual Mode:
If display was asleep, press any button to wake it up.
1. From HOME screen, use the UP or DOWN
ARROWS to select MANUAL (F
IG. 20).
2. Press center, ENTER button to confirm selec-
tion.The Manual Dispense screen (F
IG. 21) appears.
3. Squeeze trigger to dispense fluid. If using a Preset
meter, trigger may be locked during the dispense.
Fluid flows. The amount displayed counts up from zero or
from the previously dispensed amount
(F
IG. 21) and displays in field H.
4. Release, or for Preset meters only, unlock trigger
when you have dispensed the desired amount of
fluid.
Fluid flow stops. Amount dispensed displays in field H.
5. Use LEFT or RIGHT ARROW to move curser to
RESET button (G). Press center ENTER button to
reset the displayed amount in field H to zero.
F
IG. 19
MOBIL
1
5W-20
10.56
QTS
E
F
G
H
D
ti12178a
FIG. 20
F
IG. 21
MOBIL
1
5W-20
MANUAL
PRESET
TOTALS
ti12180a
Preset shown
MOBIL
1
5W-20
10.56
QTS
G
H
ti12178a
