Nozzle (33) and Extension (20) Kits
312865T 41
255857
Non-drip, quick close, high-flow nozzle with
rigid extension
Oil and
Anti-freeze
255858
Non-drip, quick close, high flow nozzle with
flexible extension
Oil and
Anti-freeze
Part No. Description Fluid Type
ti11826
ti11829
ti11825
ti11829
