G3 Pressure Relief with

Return to Reservoir

Installation Kit

Used to relieve unintended pressure rises in the system and return relieved contents back

to the reservoir. For professional use only.

Maximum Pressure: 3500 psi (241 bar, 24 MPa)

Part Nos.: 571028, 571071

Kit Parts

Important Safety Instructions

Read all warnings and instructions in this

manual and the G3 Pump instruction manual

included with your unit. Save these instructions.

Ref. Description

Qty

571028 571071

1 WASHER, sealing 2 2

2 FITTING, banjo, 1/4 npt 1 1

3 BOLT, banjo, 1/4 npt 1 0

BOLT, banjo, 1/4 bspp 0 1

4 TUBE, nylon, round 1 1

5 FITTING, 90°, elbow 2 2

6 VALVE, pressure relief 1 1

 See Pressure Relief Valves, page 2
