307878Z
EN
Instructions
50:1 Ratio Fire-Ball
®
Lubrication Pump
Portable units for heavy grease. For professional use only.
See page 2 for model information, including maximum
working pressure and approvals.
Important Safety Instructions
Read all warnings and instructions in this
manual. Save these instructions.
These systems are designed to be used only in
pumping non-corrosive and non-abrasive lubricants
and grease. Any other use of the system can cause
unsafe operating conditions and result in component
rupture, fire, or explosion which can cause serious
injury, including fluid injection.
Model 240883 shown
