Installation
3A3101D 15
Outlet Pressure
psi (MPa, bar)
5/8 in. Fluid Plunger Pumps
Minimum Gas Pressure
psi (MPa, bar)
1.25 in. Air Motor 1.75 in. Air Motor 2 in. Air Motor
0 (0, 0) 50 (0.34, 3.4) 50 (0.34, 3.4) 50 (0.34, 3.4)
75 (0.5, 5.2) 68 (0.47, 4.7) 50 (0.34, 3.4) 50 (0.34, 3.4)
150 (1, 10.3) 87 (0.60, 6.0) 50 (0.34, 3.4) 50 (0.34, 3.4)
225 (1.6, 15.5) 106 (0.73, 7.3) 54 (0.37, 3.7) 50 (0.34, 3.4)
300 (2.1, 20.7) 125 (0.86, 8.6) 64 (0.44, 4.4) 50 (0.34, 3.4)
375 (2.6, 25.9) 143 (0.99, 9.9) 73 (0.50, 5.0) 56 (0.39, 3.9)
450 (3.1, 31) 162 (1.12, 11.2) 83 (0.57, 5.7) 63 (0.44, 4.4)
525 (3.6, 36.2) 181 (1.25, 12.5) 92 (0.64, 6.4) 71 (0.49, 4.9)
600 (4.1, 41.4) 200 (1.38, 13.8) 102 (0.70, 7.0) 78 (0.54, 5.4)
675 (4.7, 46.5) - 111 (0.77, 7.7) 85 (0.59, 5.9)
750 (5.2, 51.7) - 121 (0.83, 8.3) 93 (0.64, 6.4)
825 (5.7, 56.9) - 131 (0.90, 9.0) 100 (0.69, 6.9)
900 (6.2, 62.1) - 140 (0.97, 9.7) 107 (0.74, 7.4)
975 (6.7, 67.2) - 150 (1.03, 10.3) 115 (0.79, 7.9)
1050 (7.2, 72.4) - 159 (1.10, 11.0) 122 (0.84, 8.4)
1125 (7.8, 77.6) - 169 (1.16, 11.6) 129 (0.89, 8.9)
1200 (8.3, 82.7) - 178 (1.23, 12.3) 137 (0.94, 9.4)
1275 (8.8, 87.9) - 188 (1.30, 13.0) 144 (0.99, 9.9)
1350 (9.3, 93.1) - 198 (1.36, 13.6) 151 (1.04, 10.4)
1425 (9.8, 98.3) - - 159 (1.09, 10.9)
1500 (10.3, 103.4) - - 166 (1.14, 11.4)
1575 (10.9, 108.6) - - 173 (1.19, 11.9)
1650 (11.4, 113.8) - - 181 (1.24, 12.4)
1725 (11.9, 118.9) - - 188 (1.30, 13.0)
1800 (12.4, 124.1) - - 195 (1.35, 13.5)
