Installation
16 3A3101D
Outlet Pressure
psi (MPa, bar)
3/4 in. Fluid Plunger Pumps
Minimum Gas Pressure
psi (MPa, bar)
1.25 in. Air Motor 1.75 in. Air Motor 2 in. Air Motor
0 (0, 0) 50 (0.34, 3.4) 50 (0.34, 3.4) 50 (0.34, 3.4)
50 (0.3, 3.4) 68 (0.47, 4.7) 50 (0.34, 3.4) 50 (0.34, 3.4)
100 (0.7, 6.9) 86 (0.59, 5.9) 44 (0.30, 3.0) 50 (0.34, 3.4)
150 (1, 10.3) 104 (0.72, 7.2) 53 (0.36, 3.6) 41 (0.28, 2.8)
200 (1.4, 13.8) 122 (0.84, 8.4) 62 (0.43, 4.3) 48 (0.33, 3.3)
250 (1.7, 17.2) 140 (0.96, 9.6) 71 (0.49, 4.9) 55 (0.38, 3.8)
300 (2.1, 20.7) 158 (1.09, 10.9) 80 (0.55, 5.5) 62 (0.42, 4.2)
350 (2.4, 24.1) 176 (1.21, 12.1) 90 (0.62, 6.2) 69 (0.47, 4.7)
400 (2.8, 27.6) 194 (1.34, 13.4) 99 (0.68, 6.8) 76 (0.52, 5.2)
450 (3.1, 31) 108 (0.74, 7.4) 83 (0.57, 5.7)
500 (3.4, 34.5) - 117 (0.81, 8.1) 90 (0.62, 6.2)
550 (3.8, 37.9) - 126 (0.87, 8.7) 97 (0.67, 6.7)
600 (4.1, 41.4) - 136 (0.93, 9.3) 104 (0.72, 7.2)
650 (4.5, 44.8) - 145 (1.00, 10.0) 111 (0.76, 7.6)
700 (4.8, 48.3) - 154 (1.06, 10.6) 118 (0.81, 8.1)
750 (5.2, 51.7) - 163 (1.12, 11.2) 125 (0.86, 8.6)
800 (5.5, 55.2) - 172 (1.19, 11.9) 132 (0.91, 9.1)
850 (5.9, 58.6) - 181 (1.25, 12.5) 139 (0.96, 9.6)
900 (6.2, 62.1) - 191 (1.31, 13.1) 146 (1.01, 10.1)
950 (6.6, 65.5) - 200 (1.38, 13.8) 153 (1.05, 10.5)
1000 (6.9, 68.9) - - 160 (1.10, 11.0)
1050 (7.2, 72.4) - - 167 (1.15, 11.5)
1100 (7.6, 75.8) - - 174 (1.20, 12.0)
1150 (7.9, 79.3) - - 181 (1.25, 12.5)
1200 (8.3, 82.7) - - 188 (1.30, 13.0)
1250 (8.6, 86.2) - - 195 (1.35, 13.5)
