Graco 10:1 President [14/16] Technical data

14 308738

Technical Data

Category Data

Ratio 10:1

Maximum fluid working pressure 62 bar (6.2 MPa, 900 psi)

Maximum air input pressure 6.2 bar (0.62 MPa, 90 psi)

Fluid flow at 60 cycles per minute 11 liters/min (3 gpm)

Maximum pump operating temperature 82_C (180_F)

Wetted parts Refer to manual 307044.

Sound Pressure Levels (dBa)

(measured at 1 meter from unit)

Input Air Pressures at 15 cycles per minute

Air Motor 2.8 bar (0.28 MPa, 40 psi) 4.8 bar (0.48 MPa, 70 psi) 7 bar (0.7 MPa, 100 psi)

President 73.6 dB(A) 78.3 dB(A) 80.9 dB(A)

Sound Power Levels (dBa)

(tested in accordance with ISO 9614–2)

Input Air Pressures at 15 cycles per minute

Air Motor 2.8 bar (0.28 MPa, 40 psi) 4.8 bar (0.48 MPa, 70 psi) 7 bar (0.7 MPa, 100 psi)

President 87.4 dB(A) 92.1 dB(A) 94.6 dB(A)
