Industrial Secure Router User's Manual EDR-G902/G903 Series Features and Functions
4-18
Subnet Mask
Setting Description Factory Default
IP Address The subnet mask None
Gateway
Setting Description Factory Default
IP Address The Gateway IP address None
Detailed Explanation of PPPoE Type
PPPoE Dialup
User Name
Setting Description Factory Default
Max. 30 characters The User Name for logging in to the PPPoE server None
Host Name
Setting Description Factory Default
Max. 30 characters User-defined host name for this PPPoE server None
Password
Setting Description Factory Default
Max. 30 characters The login password for this PPPoE server None
