PT-7528 Series Advanced Settings

4-37

Configuring Traffic Prioritization

Quality of Service (QoS) provides a traffic prioritization capability to ensure that important data is delivered

consistently and predictably. The Moxa switch can inspect IEEE 802.1p/1Q layer 2 CoS tags, and even layer 3

TOS information, to provide a consistent classification of the entire network. The Moxa switch’s QoS capability

improves your industrial network’s performance and determinism for mission critical applications.

QoS

The Moxa PowerTrans Series switch provides IEC 61850 Quality of Service (QoS). Once you enable IEC

61850 QoS, the packet priority of GOOSE/SMV/PTP is higher than other packets’ type.

Enable Packet Priority

Setting Description Factory Default

Enable IEC 61850 QoS Enables or disables IEC 61850 OoS function. disables

GOOSE

Setting Description Factory Default

High/Medium/Normal/

Low

The priority sequence is High>Medium>Normal>Low. We

recommend setting GOOSE packet as high priority.

High

SMV

Setting Description Factory Default

High/Medium/Normal/

Low

The priority sequence is High>Medium>Normal>Low. We

recommend setting SMV packet as high priority.

High

PTP

Setting Description Factory Default

High/Medium/Normal/

Low

The priority sequence is High>Medium>Normal>Low. High

QoS Classification

There are two QoS classification settings depending on the specific model of the switch.
