Industrial Ethernet Solutions
IKS-6728A-8PoE Series
Introduction
The Moxa IKS-6728A-8PoE series of Gigabit modular managed PoE+
Ethernet switches are designed to meet the demands of mission
critical applications for business and industry. The IKS-6728A-8PoE
comes standard with up to 24 10/100BaseT(X), or PoE/PoE+, and 4
combo Gigabit Ethernet ports. The IKS-6728A-8PoE Ethernet switches
provide up to 30 watts of power per PoE+ port in standard mode,
and also support high power output of up to 36 watts for heavy-duty
industrial PoE devices, such as weather-proof IP surveillance cameras
with wipers/heaters, high-performance wireless access points, and
rugged IP phones. IKS-6728A-8PoE Ethernet switches support two
• Advanced PoE management functions: PoE output setting, PD
failure check, PoE scheduling, and PoE diagnostics
• Command Line Interface (CLI) for quickly configuring major
managed functions
• Software-based IEEE 1588 PTPv2 (Precision Time Protocol) for
time synchronization of networks
• DHCP Option 82 for IP address assignment with different policies
• Support EtherNet/IP and Modbus/TCP protocols for device
management and monitoring
• Compatible with PROFINET protocol for transparent data
transmission
• Turbo Ring and Turbo Chain (recovery time < 20 ms @ 250
switches), RSTP/STP, and MSTP for network redundancy
• IGMP snooping and GMRP for filtering multicast traffic
• Port-based VLAN, IEEE 802.1Q VLAN, and GVRP to ease network
planning
24+4G-port Gigabit modular managed PoE+ Ethernet switches
types of power input sources: 48 VDC for PoE+ ports and system
power, and 110/220 VAC for system power. These Ethernet switches
also support a variety of management functions, including STP/RSTP,
Turbo Ring, Turbo Chain, PoE power management, PoE device auto-
checking, PoE power scheduling, PoE diagnostic, IGMP, VLAN, QoS,
RMON, bandwidth management, and port mirroring. The IKS-6728A-
8PoE series is designed especially for harsh outdoor applications with
3kV surge protection to ensure the uninterrupted reliability of PoE
systems.
• QoS (IEEE 802.1p/1Q) and TOS/DiffServ to increase determinism
• IEEE 802.3ad, LACP for optimum bandwidth utilization
• TACACS+, IEEE 802.1X, SNMPv3, HTTPS, and SSH to enhance
network security
• SNMPv1/v2c/v3 for different levels of network management
• RMON for efficient network monitoring and proactive capability
• Bandwidth management prevents unpredictable network status
with “Lock port” to restrict access to authorized MAC addresses
• Port mirroring for online debugging
• Automatic warning by exception through email, relay output
• Automatic recovery of connected device’s IP addresses
• Line-swap fast recovery
• Configurable by web browser, Telnet/serial console, CLI, Windows
utility, and ABC-02-USB automatic backup configurator
Features and Benefits
› 8 built-in PoE+ ports compliant with IEEE 802.3af/at
› Up to 36 W output per PoE+ port
› 3 kV LAN surge protection for extreme outdoor environments
› PoE diagnostics for powered-device mode analysis
› 4 Gigabit combo ports for high bandwidth communication
› -40 to 75°C operating temperature range at 720 W full loading
› Supports MXstudio for easy, visualized industrial network
management
› V-ON™ ensures millisecond-level multicast data and video
network recovery
