Moxa Command Line Interface (FW_5.x) Commands
2-138
Examples
MOXA# configure terminal
MOXA(config)# redundancy
MOXA(config)# spanning-tree mst instance 1 vlan 2
Error
messages
The instance id must be in the range from 1 to 16.
vlan 4097 is invalid!! should be range from 1 to 4094
The maximum VLAN mapping is 64.
The vlan id 2 setting is exist in another instance.
MSTI 1 vlan id 2 set error
Related
commands
show redundancy mst instance
spanning-tree mst instance cost
Use the spanning-tree mst instance cost interface configuration command on the switch to set the port cost
of the MSTP instances. Use the no form of this command to return to the default setting.
Commands
spanning-tree mst instance instance-id-list cost cost
no spanning-tree mst instance instance-id-list cost
Syntax
Description
spanning-tree Configure spanning tree
mst Configure mstp
instance Configure mstp msti port
instance-id-list MSTP instance IDs
cost Configure mstp msti port path cost
cost Configure mstp msti port path cost
Defaults cost =0
Command
Modes
Interface configuration
Usage
Guidelines
N/A
Examples
MOXA(config-if)# spanning-tree mst cist cost 0
<UINT:cost> - Configure mstp msti port path cost
Error
messages
MSTP port path cost must be in the range from 0 to 200000000
MSTP forward delay set error
Related
commands
show redundancy mst configuration
spanning-tree mst instance port-priority
Use the spanning-tree mst instance port-priority interface configuration command on the switch to set the
port priority for the MSTP instances. Use the no form of this command to return to the default setting.
Commands
spanning-tree mst instance instance-id-list port-priority priority
no spanning-tree mst instance instance-id-list port-priority
Syntax
Description
spanning-tree Configure spanning tree
mst Configure mstp
instance Configure mstp msti port
instance-id-list MSTP instance ID
port-priority Configure mstp msti port priority
priority Configure mstp msti port priority
Defaults priority =128
