Moxa Command Line Interface (FW_5.x) Commands
2-160
vlan mode
Use the vlan mode configuration command on the switch to change current VLAN mode operated on the
switch. Use the no form of this command to return to the default.
Commands
vlan mode { 1qvlan | pvlan }
no vlan mode
Syntax
Description
vlan Configure VLAN parameters
mode Set vlan mode
1qvlan IEEE 802.1Q
pvlan Port-based vlan
Defaults The default mode is 802.1Q mode in the product with 802.1Q supported; otherwise is
port-based VLAN mode.
Command
Modes
Global configuration
Usage
Guidelines
N/A
Examples
MOXA# configure terminal
MOXA(config)# vlan mode 1qvlan
MOXA(config)# vlan mode pvlan
Error
messages
Port-based VLAN is only supported when IGMP Snooping is disabled
Related
commands
vlan default
vlan set
Use the vlan set global configuration command on the switch to set name for specific VLAN. Use the no form
of this command to reset VLAN name.
Commands
vlan set vlanid name [token1] [token2] [token3] [token4] [token5]
no vlan set vlanid name
Syntax
Description
vlan Configure VLAN parameters
set set <vid> name <name>
vlanid set <vid> name <name>
name set <vid> name <name>
token1 set <vid> name <name> (maximum 30 characters)
token2 set <vid> name <name> (maximum 30 characters)
token3 set <vid> name <name> (maximum 30 characters)
token4 set <vid> name <name> (maximum 30 characters)
token5
set <vid> name <name> (maximum 30 characters)
Defaults NULL
Command
Modes
Global configuration
Usage
Guidelines
vlanid is range from 1 to 4094
VLAN name is a string containing token1 to token5 sperated by space
for example: vlan set 5 name a b c d e will result VLAN name in “a b c d e”
Examples
MOXA# configure terminal
MOXA(config)# vlan set 2 name vlan1
