MartinLogan Dynamo [12/24] Ac power connection replacing the fuse

WARNING! The power cord should not be

installed, removed, or left detached from the

subwoofer while the other end is connected to

an AC power source.

The IEC power cord should be firmly inserted into the

AC power receptacle on the rear connection panel of

the Dynamo, then to any convenient AC wall outlet. The

Dynamo also integrates a signal sensing power supply

that automatically switches off after sensing no music signal

for several minutes (this will occur when the power switch

is set to 'Auto').

Your Dynamo subwoofer is wired for the power service sup

plied in the country of original consumer sale. The AC power

rating applicable to a particular unit is specified both on the

packing carton and on the serial number plate attached to

the subwoofer.

If you remove your Dynamo subwoofer from the country of

original sale, be certain that AC power supplied in any sub

sequent location is suitable before connecting and operating

the subwoofer. Substantially impaired performance or severe

damage may occur to the Dynamo subwoofer if operation is

attempted from an incorrect AC power source.

If the fuse in your Dynamo should require changing, turn off

and unplug your Dynamo before removing the fuse. Replace

the bad fuse with a matching T 2A L 250V (T 1A L 250V if

you are in a region using 230v–240v current).

Break-In

Our custom made woofers require approximately 50 hours

of break-in at moderate listening levels before their optimal

performance occurs. This will factor in on any critical listening

and judgment.

12 Connections and Control Settings

AC Power Connection Replacing the Fuse

Figure 13. IEC power cord AC receptacle and fuse.
