- 13 -
a. 50/125 μm, 800 MHz*km fiber optic cable
b. 62.5/125 μm, 500 MHz*km fiber optic cable
c. 9/125 μm, 3.5 PS/(nm*km) fiber optic cable
Physical Characteristics
Housing Metal
Dimensions (W x H x D)
144.45 x 110.2 x 51.65 mm (5.69 x 4.34 x 2.03
in)
Weight Product only: 525g
Packaged: 710g
Installation
DIN-Rail mounting, Wall Mounting (optional
kit)
Environmental Limits
Operating Temperature
Standard Models: 0 to 60
o
C (32 to 140
o
F)
Wide Temp. Models: -40 to 75
o
C (-40 to 167
o
F)
Storage Temperature -40 to 85
o
C (-40 to 185
o
F)
Ambient Relative
Humidity
5 to 90% (non-condensing)
Power Requirements
Input Voltage 48VDC (46 to 57 VDC), redundant inputs
Power Consumption 430mA@48VDC (max.)
Connection Removable terminal block
Overload Current Protection
1.6 A (protects against two signals shorted
together)
Reverse Polarity Protection Present
Regulatory Approvals
Safety UL508
EMI FCC Part 15, CISPR (EN55022) class A
EMS IEC 61000-4-2 Edition 1.2: 2001-04(Level 4)
EN 61000-3-3: 1995 + A1: 2001
IEC 61000-4-3: 2002+A1: 2002(Level 3)
IEC 61000-4-4: 2004(Level 4)
IEC 61000-4-5 Edition 1.1: 2001-04(Level 3)
IEC 61000-4-6 Edition 2.1: 2004-11(Level 3)
IEC 61000-4-8 Edition 1.1: 2001-03(Level 3)
IEC 61000-4-11 Second Edition: 2004-03
Shock IEC 60068-2-27
Free Fall IEC 60068-2-32
Vibration IEC 60068-2-6
Warranty
Warranty Period
5 years
Details: See www.moxa.com/warranty
