- 12 -
5 Flash Power overload Fault
9 Flash Power Management Allocation Exceeded
ON Ethernet port 10 Mbps link is active.
Blinking Data is being transmitted at 10 Mbps.
10M Yellow
OFF Ethernet port 10 Mbps link is inactive.
ON Ethernet port 100 Mbps link is active.
Blinking Data is being transmitted at 100 Mbps.
100M Green
OFF Ethernet port 100 Mbps link is inactive.
Specifications
Technology
Standards
IEEE 802.3 for 10BaseT,
IEEE 802.3u for 100BaseT(X), 100BaseFX
IEEE 802.3af for Power-over-Ethernet
Interface
RJ45 ports 10/100BaseT(X)
Fiber ports 100BaseFX (SC, ST connectors available)
LED Indicators
PWR1, PWR2, Fiber Link/Act, 10/100M (Ethernet
port), PSE Indicator
DIP Switches:
Dip No. Function ON OFF
1 Auto Negotiation Enable* Disable
2 Force TP Speed 100Mbps* 10Mbps
3 Force TP Duplex Full Duplex* Half Duplex
4 Link Fault Pass Through Enable* Disable
5 Operating Mode Store-and-Forward* Pass Through
6 PSE Disable Enable*
7
P.R.R.
(PD Remote Reset)
Enable Disable*
(*): Default DIP switch setting.
Alarm Contact
One relay output with current carrying capacity
of 1A @ 24 VDC
Optical Fiber
100BaseFX
Multi-mode Single-mode
Wavelength 1300 nm 1310 nm
Max. TX -10 dBm 0 dBm
Min. TX -20 dBm -5 dBm
RX Sensitivity -32 dBm -34 dBm
Link Budget 12 dB 29 dB
Typical Distance
5 km
a
4 km
b
40 km
c
Saturation -6 dBm -3 dBm
