- 9 -
LED Indicators
The front panel of the PTC-101-M12 has several LED indicators. The
function of each LED is described in the table below.
LED
Color
State
Description
PWR1 Green
On
Power is being supplied to power
input PWR1.
Off
Power is
not
being supplied to
power input PWR1.
PWR2 Green
On
Power is being supplied to power
input PWR2.
Off
Power is not being supplied to power
input PWR2.
Fiber/
Link/
Act
Green
On
Fiber port is active.
Blinking
Data is being transmitted or
received.
Off
Fiber is inactive.
10M Yellow
On
10 Mbps Ethernet port link is active.
Blinking
Data is being transmitted at
10 Mbps.
Off
10 Mbps Ethernet port link is
inactive.
100M Green
On
100 Mbps Ethernet port is active.
Blinking
Data is being transmitted at
100 Mbps.
Off
100 Mbps Ethernet port link is
inactive.
Specifications
Technology
Standards
IEEE 802.3 for 10BaseT
IEEE 802.3u for 100BaseT(X), 100BaseFX
Interface
M12 (TP) port
10/100BaseT(X)
Fiber port
100BaseFX (SC/ST connectors)
LED Indicators
PWR1, PWR2, Fiber Link, 10/100M (TP port)
Dip Switches
Dip No.
ON
OFF
1
Enable
Disable
2
100 Mbps
10 Mbps
3
Full Duplex
Half Duplex
4
Enable
Disable
5
Store-and-Forward
Pass Through
Note: Default DIP settings are in the ON position.
Alarm Contact
One relay output with current carrying
capacity of 1 A @ 24 VDC
