![Moxa AWK-1121-PoE-EU [10/13] Led indicators](/views2/1198005/page10/bga.png)
- 10 -
LED Indicators
The front panel of the Moxa AWK-1121 contains several LED indicators.
The function of each LED is described in the table below:
LED
Color
State
Description
PWR Green
On
Power is on.
Off
Power is not being supplied.
FAULT Red
On
System is booting up.
Blinking
(slow at
1-second
intervals)
IP address cannot be got from DHCP
server.
Blinking
(fast at
0.5-second
intervals)
IP address conflict.
Off
Status is normal.
STATE
Green/
Red
Green
System startup is complete and the
system is in operation.
Green
(Blinking at
1-second
intervals)
The AWK Search Utility has located
the AWK.
Red
System is booting up.
SIGNAL
(5 LEDs)
Green
On
Signal level.
Off
Reserved.
WLAN Green
On
WLAN is connected.
Blinking
WLAN is transferring data.
Off
WLAN is not in use or not working
properly.
LAN Green
Green
100/10 Mbps LAN port is active.
Blinking
Data is being transmitted.
Off
100/10 Mbps LAN port is inactive.
Specifications
WLAN Interface
Standards
IEEE 802.11a/b/g for Wireless LAN
IEEE 802.11i for Wireless Security
IEEE 802.3 for 10BaseT
IEEE 802.3u 10/100BaseT(X)
IEEE 802.3af for Power-over-Ethernet (PoE
models only)
IEEE 802.1D for Spanning Tree Protocol
IEEE 802.1w for Rapid STP
Spread Spectrum and
Modulation (typical)
• DSSS with DBPSK, DQPSK, CCK
• OFDM with BPSK, QPSK, 16QAM, 64QAM
• 802.11b:
CCK @ 11/5.5 Mbps, DQPSK @ 2 Mbps,
DBPSK @ 11 Mbps
• 802.11a/g:
64QAM @ 54/48 Mbps, 16QAM @ 36/24 Mbps
,
QPSK @ 18/12 Mbps, BPSK @ 9/6 Mbps
