- 12 -
Console Port
RS-232 (RJ45-type)
Reset
Present
LED Indicators
PWR, FAULT, STATE, SIGNAL, WLAN, LAN
Physical Characteristics
Housing
Metal, providing IP30 protection
Weight
400 g (0.9 lb)
Dimensions
50 x 115 x 70 mm
(1.98 x 4.53 x 2.76 in)
Installation
DIN-rail mounting,
wall mounting (with optional kit)
Environmental Limits
Operating
Temperature
Standard Models: 0 to 60°C (32 to 140°F)
Wide Temp. Models: -40 to 75°C (-40 to 167°F)
Storage Temperature
-40 to 85°C (-40 to 185°F)
Ambient Relative
Humidity
5% to 95% (non-condensing)
Power Requirements
Input Voltage
12 to 48 VDC, redundant dual DC power inputs or
48 VDC Power-over-Ethernet (IEEE 802.3af
compliant)*
*PoE is only available for the AWK-1121-PoE
Connector
4-pin removable terminal block
Power Consumption
12 to 48 VDC, 0.16 to 0.55 A
Reverse Polarity
Protection
Present
Standards and Certifications
Safety
UL 60950-1, EN 60950-1
EMC
EN 301 489-1/17; FCC Part 15, Subpart B Class B;
EN 55022/55024
Radio EN 300 328, EN 301 893, TELEC, FCC ID
SLE-WAPN003
Note: Please check Moxa’s website for the most up-to-date
certification status.
Reliability
MTBF
392,209 hrs.
Warranty
Warranty Period
5 years
Details
See www.moxa.com/support/warranty.aspx
ATTENTION
The AWK
-1121 is NOT a portable mobile device and should be
located
at least 20 cm away from the human body.
The AWK
-1121 is NOT designed for the general public. A
well
-trained technician is required to deploy the AWK-4131A
units and safely establish a wireless network.
