Moxa AWK-3121-SSC-RTG-EU Технические характеристики онлайн
EN 50155 Wireless LAN
1
www.moxa.com
Introduction
Specifications
Industrial IEEE 802.11a/b/g wireless AP/client
The AWK-3121-RTG 3-in-1 industrial AP/client devices are designed
specifically for train-to-ground communication while moving at speeds
of up to 120 km/h. The AWK-3121-RTG complies with a portion of EN
50155 specifications, covering operating temperature, power input
voltage, surge, ESD, and vibration, making the products suitable for
a variety of industrial applications. Installation is easy, with either
DIN-rail mounting or distribution boxes, and the DIN-rail mounting
capability, wide operating temperature range, and IP30 housing with
LED indicators make the AWK-3121-RTG a convenient yet reliable
solution for any rolling stock application.
Advanced Security
• 64-bit and 128-bit WEP (Wired Equivalent Privacy)
• Enable/disable SSID broadcasts
• WPA/WPA2 (Wi-Fi Protected Access) and 802.11i support
• IEEE802.1X/RADIUS support
• Powerful filters for access control
Specifications for Train-to-Ground Applications
• Client-based Turbo Roaming handover time
< 150 ms @ 1 channel with WPA2
< 350 ms @ 3 channels with WPA2
• Controller-based Turbo Roaming handover time (available only
when used with the WAC-1001 or WAC-2004)
< 50 ms @ 3 channels with WPA2
• Multiple roaming parameters for different installation structures
and antenna types
› IEEE 802.11a/b/g compliant
› M12 anti-vibration connectors (AWK-3121-M12-RTG and
AWK-3121-M12-HP-RTG)
› QoS (WMM) and VLAN for efficient network traffic
› Controller-based Turbo Roaming (handover time < 50 ms @ 3
channels, WPA2); available only when used with the WAC-1001 or
WAC-2004
› Supports long-distance data transfer (AWK-3121-M12-HP-RTG)
› Complies with a portion of EN 50155 specifications
› -40 to 75°C operating temperature range (T models)
AWK-3121-RTG Series
WLAN Interface
Standards:
IEEE 802.11a/b/g for Wireless LAN
IEEE 802.11i for Wireless Security
IEEE 802.3 for 10BaseT
IEEE 802.3u for 100BaseTX
IEEE 802.3af for Power-over-Ethernet
Spread Spectrum and Modulation (typical):
•DSSSwithDBPSK,DQPSK,CCK
•OFDMwithBPSK,QPSK,16QAM,64QAM
•802.11b:CCK@11/5.5Mbps,DQPSK@2Mbps,
DBPSK @ 1 Mbps
•802.11a/g:64QAM@54/48Mbps,16QAM@36/24Mbps,
QPSK@18/12Mbps,BPSK@9/6Mbps
Operating Channels (central frequency):
US:
2.412 to 2.462 GHz (11 channels)
5.18 to 5.24 GHz (4 channels)
5.26 to 5.825 GHz (optional)
EU:
2.412 to 2.472 GHz (13 channels)
5.18 to 5.24 GHz (4 channels)
5.26 to 5.825 GHz (optional)
*Specialbands,suchas5.9GHz,arecustomizable.
Security:
•SSIDbroadcastenable/disable
•FirewallforMAC/IP/Protocol/Port-basedltering
•64-bitand128-bitWEPencryption,WPA/WPA2-Personaland
Enterprise (IEEE 802.1X/RADIUS, TKIP, and AES)
Transmission Rates:
802.11b:1,2,5.5,11Mbps
802.11a/g:6,9,12,18,24,36,48,54Mbps
TX Transmit Power:
AWK-3121-M12-RTGandAWK-3121-SSC-RTG:
802.11b:
Typ. 23±1.5 dBm @ 1 to 11 Mbps
802.11g:
Typ.20±1.5dBm@6to24Mbps,Typ.19±1.5dBm@36Mbps,Typ.
18±1.5 dBm @ 48 Mbps, Typ. 17±1.5 dBm @ 54 Mbps
802.11a:
Typ. 18±1.5 dBm @ 6 to 24 Mbps, Typ. 16±1.5 dBm @ 36 to 48 Mbps,
Typ. 15±1.5 dBm @ 54 Mbps
AWK-3121-M12-HP-RTG:
802.11b:
Typ. 26±1.5 dBm @ 1 to 11 Mbps
802.11g:
Typ. 26±1.5 dBm @ 6 to 24 Mbps, Typ. 25±1.5 dBm @ 36 Mbps, Typ.
24±1.5 dBm @ 48 Mbps, Typ. 23±1.5 dBm @ 54 Mbps
