Industrial Wireless LAN Solutions

www.moxa.com

AWK-4121 Series

Industrial IEEE 802.11a/b/g IP68 wireless AP/bridge/client

The AWK-4121 outdoor wireless AP/bridge/client is the ideal outdoor

wireless solution for industrial applications that are hard to wire,

too expensive to wire, or use mobile equipment that connect to a

TCP/IP network. The AWK-4121’s dust-tight/weatherproof design is

IP68-rated, allowing you to extend existing wired networks to outdoor

locations and critical environments. The two redundant DC power

inputs increase the reliability of the power supply and can be powered

via PoE for easier deployment. The AWK-4121 complies with a portion

of EN 50155 specifications, covering operating temperature, power

input voltage, surge, ESD, and vibration, making the switches suitable

for a variety of industrial applications.

Features for Critical Environments

• IP68-rated metal housing and -40 to 75°C wide operating

temperature

• Anti-vibration M12 design and waterproof/dust-tight RJ45

connectors

• PoE and dual DC power inputs

Speciﬁcations for Industrial-grade Applications

• Long-distance wireless transmission over 10 km

• Integrated DI/DO for on-site monitoring and warnings

• Status LED indicators for on-site monitoring and diagnosis

Introduction

Speciﬁcations

› IEEE 802.11a/b/g compliant

› Redundant dual DC power inputs or PoE

› QoS (WMM) and VLAN for efﬁcient network trafﬁc

› Supports long-distance data transfer and 100 ms Turbo Roaming

› Rugged IP68-rated housing

› Complies with a portion of EN 50155 speciﬁcations

› -40 to 75°C operating temperature

WLAN Interface

Standards:

IEEE 802.11a/b/g for Wireless LAN

IEEE 802.11i for Wireless Security

IEEE 802.3 for 10BaseT

IEEE 802.3u for 100BaseT(X)

IEEE 802.3af for Power-over-Ethernet

IEEE 802.1D for Spanning Tree Protocol

IEEE 802.1w for Rapid STP

IEEE 802.1Q for VLAN

Spread Spectrum and Modulation (typical):

•DSSSwithDBPSK,DQPSK,CCK

•OFDMwithBPSK,QPSK,16QAM,64QAM

•802.11b:CCK@11/5.5Mbps,DQPSK@2Mbps,

DBPSK@11Mbps

•802.11a/g:64QAM@54/48Mbps,16QAM@36/24Mbps,

QPSK@18/12Mbps,BPSK@9/6Mbps

Operating Channels (central frequency):

US:

2.412 to 2.462 GHz (11 channels)

5.18 to 5.24 GHz (4 channels)

EU:

2.412 to 2.472 GHz (13 channels)

5.18 to 5.24 GHz (4 channels)

JP:

2.412to2.472GHz(13channels,OFDM)

2.412 to 2.484 GHz (14 channels, DSSS)

5.18 to 5.24 GHz (4 channels)

Security:

•SSIDbroadcastenable/disable

•FirewallforMAC/IP/Protocol/Port-basedltering

•64-bitand128-bitWEPencryption,WPA/WPA2Personaland

Enterprise (IEEE 802.1X/RADIUS, TKIP and AES)

Transmission Rates:

802.11b:1,2,5.5,11Mbps

802.11a/g:6,9,12,18,24,36,48,54Mbps

TX Transmit Power (for hardware revision 1.1):

802.11b:

Typ.23±1.5dBm@1to11Mbps

802.11g:

Typ.20±1.5dBm@6to24Mbps,Typ.19±1.5dBm@36Mbps,Typ.

18±1.5dBm@48Mbps,Typ.17±1.5dBm@54Mbps

802.11a:

Typ.18±1.5dBm@6to24Mbps,Typ.16±1.5dBm@36to48Mbps,

Typ.15±1.5dBm@54Mbps

TX Transmit Power (for hardware revision 1.0):

802.11b:

Typ.18±1.5dBm@1to11Mbps

802.11g:

Typ.18±1.5dBm@6to24Mbps,Typ.16±1.5dBm@36to48Mbps,

Typ.15±1.5dBm@54Mbps

802.11a:

Typ.16±1.5dBm@6to24Mbps,Typ.14±1.5dBm@36to48Mbps,

Typ.13±1.5dBm@54Mbps

RX Sensitivity (for hardware revision 1.1):

802.11b:

-97dBm@1Mbps,-94dBm@2Mbps,-92dBm@5.5Mbps,-90

dBm@11Mbps
