Moxa AWK-4121-EU-T [2/2] Ordering information

Industrial Wireless LAN Solutions

2

©MoxaInc.Allrightsreserved.UpdatedMar.16,2015.Specicationssubjecttochangewithoutnotice.Pleasevisitourwebsiteforthemostup-to-dateproductinformation.

802.11g:

-93dBm@6Mbps,-91dBm@9Mbps,-90dBm@12Mbps,-88

dBm@18Mbps,-84dBm@24Mbps,-80dBm@36Mbps,-76dBm

@48Mbps,-74dBm@54Mbps

802.11a:

-90dBm@6Mbps,-89dBm@9Mbps,-89dBm@12Mbps,-85

802.11g:

-87dBm@6Mbps,-86dBm@9Mbps,-85dBm@12Mbps,-82

dBm@18Mbps,-80dBm@24Mbps,-76dBm@36Mbps,-72dBm

@48Mbps,-70dBm@54Mbps

802.11a:

-87dBm@6Mbps,-86dBm@9Mbps,-85dBm@12Mbps,-82

dBm@18Mbps,-80dBm@24Mbps,-76dBm@36Mbps,-72dBm

@48Mbps,-70dBm@54Mbps

Protocol Support

General Protocols: Proxy ARP, DNS, HTTP, HTTPS, IP, ICMP, SNTP,

RJ45 Ports:1,10/100BaseT(X),autonegotiationspeed,F/Hduplex

mode, and auto MDI/MDI-X connection

Console Port: RS-232 (waterproof RJ45-type)

Reset: Present

LED Indicators:PWR,FAULT,STATE,WLAN,LAN

Alarm Contact (digital output, M12 female connector): 1 relay output

withcurrentcarryingcapacityof1A@24VDC

Digital Inputs (M12 female connector): 2 electrically isolated inputs

•+13to+30Vforstate“1”

•+3to-30Vforstate“0”

•Max.inputcurrent:8mA

Physical Characteristics

Housing: Metal, IP68 protection

Weight: 1.5 kg

Ambient Relative Humidity: 5% to 100% (non-condensing)

Power Requirements

Input Voltage: 12 to 48 VDC, redundant dual DC power inputs or 48

VDC Power-over-Ethernet (IEEE 802.3af compliant)

Connector: M12 male connector with A-coding

Power Consumption:12to48VDC,0.121to0.494A

Reverse Polarity Protection: Present

Standards and Certifications

Safety:UL60950-1,EN60950-1

Hazardous Location: UL/cUL Class I Division 2, ATEX Zone 2

Reliability

MTBF (mean time between failures): 364,564 hrs

Warranty

Warranty Period: 5 years

Details: See www.moxa.com/warranty

Package Checklist

• AWK-4121 wireless AP/bridge/client

• 2 omni-directional antennas (5/2 dBi, N-type male,

2.4/5 GHz)

• Wall mounting kit (includes 2 supports)

• Quick installation guide (printed)

• Warranty card

Available Models

AWK-4121-US-T: IEEE 802.11a/b/g IP68 wireless AP/bridge/client, US band, -40 to 75°C

operating temperature

AWK-4121-EU-T: IEEE 802.11a/b/g IP68 wireless AP/bridge/client, EU band, -40 to 75°C

operating temperature

AWK-4121-JP-T: IEEE 802.11a/b/g IP68 wireless AP/bridge/client, JP band, -40 to 75°C

operating temperature
