EN 50155 Wireless LAN
Introduction
Specifications
Railway trackside 802.1 a/b/g IP68 wireless unit
The TAP-6226 trackside wireless unit is designed for train-to-ground
wireless communication. It is a highly compact and rugged wireless
unit that integrates two access points, a managed fiber switch, and
a wide-range AC/DC power supply, all in one box. The IP68 housing
can withstand the harshest weather, and M12 connectors make the
unit shock and vibration resistant. The TAP-6226 supports advanced
controller-based Turbo Roaming technology for applications such
as Communication-Based Train Control (CBTC). The unit can
supply power to up to 4 PoE devices while providing reliable LAN
communication with Moxa’s Turbo Chain technology.
Advanced Mobility and Reliability
• Controller-based L3 Turbo Roaming
• Mobile IP support
• 2 dual-band radios: 2.4 GHz and 5.1 to 5.9 GHz
• Turbo Chain support (100 ms recovery time)
• WPA/WPA2 and 802.11i support
• IEEE 802.1X/RADIUS support
Built for Transportation Applications
• Isolated 110 to 220 VDC/VAC power input
• High transmission power, 400 mW
• Supplies power through 4 PoE ports (PSE)
• 2 fiber SFP ports for backbone installation
• Wide temperature (-40 to 75°C) and IP68 housing
TAP-6226 Series
› 2 dual-band radios, IEEE 802.11a/b/g compliant
› Railway approved IP68 housing
› Controller-based Turbo Roaming
› 2 fiber SFP ports and 4 PoE ports with M12 LAN connectors
› High transmission power for extended reach
› Complies with a portion of EN 50155 specifications
› -40 to 75°C operating temperature range
WLAN Interface
Standards:
IEEE 802.11a/b/g for Wireless LAN
IEEE 802.11i for Wireless Security
IEEE 802.3 for 10BaseT
IEEE 802.3u for 100BaseTX
IEEE 802.3af for Power-over-Ethernet
IEEE 802.1D for Spanning Tree Protocol
IEEE 802.1w for Rapid STP
IEEE 802.1p for Class of Service
IEEE 802.1Q for VLAN
Spread Spectrum and Modulation (typical):
•DSSSwithDBPSK,DQPSK,CCK
•OFDMwithBPSK,QPSK,16QAM,64QAM
•802.11b:CCK@11/5.5Mbps,DQPSK@2Mbps,DBPSK@1Mbps
•802.11a/g:64QAM@54/48Mbps,16QAM@36/24Mbps,QPSK@
18/12Mbps,BPSK@9/6Mbps
Operating Channels (central frequency):
US:
2.412 to 2.462 GHz (802.11a/b/g, 11 channels)
5.18 to 5.24 GHz (802.11a, 4 channels)
5.26 to 5.825 GHz (optional)
EU:
2.412 to 2.472 GHz (802.11abg, 13 channels)
5.18 to 5.24 GHz (802.11a, 4 channels)
5.26 to 5.825 GHz (optional)
*Special frequency bands (such as 5.9 GHz) is available for customization.
Security:
•SSIDbroadcastenable/disable
•FirewallforMAC/IP/Protocol/Port-basedltering
•64-bitand128-bitWEPencryption,WPA/WPA2-Personaland
Enterprise(IEEE802.1X/RADIUS,TKIP,andAES)
Transmission Rates:
802.11b: 1, 2, 5.5, 11 Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
TX Transmit Power:
802.11b:
Typ.26±1.5dBm@1to11Mbps
802.11g:
Typ.26±1.5dBm@6to24Mbps,Typ.25±1.5dBm@36Mbps,Typ.
24±1.5dBm@48Mbps,Typ.23±1.5dBm@54Mbps
802.11a:
Typ.26±1.5dBm@6toMbps,Typ.25±1.5dBm@36Mbps,Typ.
24±1.5dBm@48Mbps,Typ.23±1.5dBm@54Mbps
RX Sensitivity:
802.11b:
-97dBm@1Mbps,-94dBm@2Mbps,-92dBm@5.5Mbps,-90
dBm@11Mbps
802.11g:
-93dBm@6Mbps,-91dBm@9Mbps,-90dBm@12Mbps,-88
dBm@18Mbps,-84dBm@24Mbps,-80dBm@36Mbps,-76dBm
@48Mbps,-74dBm@54Mbps
802.11a:
-90dBm@6Mbps,-89dBm@9Mbps,-89dBm@12Mbps,-85
dBm@18Mbps,-83dBm@24Mbps,-79dBm@36Mbps,-75dBm
@48Mbps,-74dBm@54Mbps
1
www.moxa.com
