EN 50155 Wireless LAN
Ordering Information
Available Models
TAP-6226-TC-US-T: Rugged trackside wireless access point, US band
TAP-6226-TC-EU-T: Rugged trackside wireless access point, EU band
Optional Accessories (can be purchased separately)
SFP-1FESLC-T: Small form factor pluggable transceiver with 100Base single-mode, LC connector,
40 km, -40 to 85°C operating temperature
SFP-1FELLC-T: Small form factor pluggable transceiver with 100Base single-mode, LC connector,
80 km, -40 to 85°C operating temperature
CBL-M23 (FF 6P)/OPEN-BK-100 IP67: 1-meter M23 to 6-pin power cable with IP67-rated female
6-pin M23 connector
Package Checklist
• TAP-6226 trackside wireless unit
• 5 protective caps for console port and
LAN ports
• Fiber panel-mounting kit
• Wall-mounting kit
• Warranty card
Protocol Support
General Protocols: Proxy ARP, DNS, HTTP, HTTPS, IP, ICMP, SNTP,
TCP, UDP, RADIUS, SNMP v1/v2/v3, PPPoE, DHCP, STP/RSTP
Interface
Connector for External Antennas: N-type (female)
Fiber Ports: 2, 100BaseSFP slot
Console Port: M12 A-coded 5-pin male connector
LED Indicators: PWR1, PWR2, PoE1-4, FAULT, STATE, HEAD, TAIL,
LAN1-6, WLAN1, WLAN2
Fast Ethernet ports: 4, side cabling, M12 D-coded 4-pin female
connector, 10/100BaseT(X) auto negotiation speed, F/H duplex mode,
and auto MDI/MDI-X connection, 802.1af PoE power budget
Fiber Module: 100Base multi-mode 1300 nm wavelength with LC
connector for 4 km transmission (50/125 µm or 62.5/125 µm 800
MHz-km@1300nmwavelength)
Connector Conduit PG Thread Size
Antenna Ports
PG29
Power Port
PG36
Physical Characteristics
Housing: Metal, IP68 protection
Weight: 9.7 kg (21.38 lb)
Dimensions: 324 x 279 x 156 mm (12.76 x 10.98 x 6.14 in)
Installation: Wall mounting
Environmental Limits
Operating Temperature: -40 to 75°C (-40 to 167°F)
Storage Temperature: -40 to 85°C (-40 to 185°F)
Ambient Relative Humidity: 5% to 95% (non-condensing)
Power Requirements
Input Voltage: 110/220 VDC/VAC
Input Current:0.68A@110VDC/VAC
Connector: M23
Power Consumption: 74.8 W (max., with PoE ports fully loaded), 15 W
(without PoE)
Reverse Polarity Protection: Present
Overload Current Protection: Present
Standards and Certifications
Safety: UL 60950-1, EN 60950-1 (CB)
EMC: EN 55022/24, EN 61000-6-2/6-4
EMI: CISPR 22, FCC Part 15B Class A
EMS:
IEC 61000-4-2 ESD: Contact: 8 kV; Air: 15 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 20 V/m
IEC 61000-4-4 EFT: Power: 2 kV; Signal: 2 kV
IEC 61000-4-5 Surge: Power: 2 kV; Signal: 2 kV
IEC 61000-4-6 CS: 10 V
IEC 61000-4-8
Radio: EN 301 489-1/17, EN 300 328, EN 301 893, FCC ID SLE-
WAPA004
Rail Traffic: EN 50155*, EN45545-2, EN 50121-4
*Complies with a portion of EN 50155 specifications.
Note: Please check Moxa’s website for the most up-to-date certification status.
MTBF (mean time between failures)
Time: 382,735 hrs
Standard: Telcordia SR332
Warranty
Warranty Period: 5 years
Details: See www.moxa.com/warranty
Dimensions
Unit: mm (inch)
156 (6.14)
324 (12.76)
356 (14.02)
279 (10.98)
2
© Moxa Inc. All rights reserved. Updated Mar. 28, 2016. Specifications subject to change without notice. Please visit our website for the most up-to-date product information.
