www.moxa.com

Industrial Wireless LAN Solutions

Speciﬁcations

AWK-5222 Series

Industrial IEEE 802.11a/b/g dual-radio wireless AP/bridge/client

Moxa’s wireless redundancy technology allows you to set up

independent wireless connections to avoid interruptions in

transmission, even if interference occurs on one of the supported

frequencies. The AWK-5222 is equipped with the newest proprietary

wireless redundancy technology, which has two independent RF

modules, and supports a greater variety of wireless configurations

and applications. The redundant wireless connections increase the

reliability of the entire wireless network. The AWK-5222 is compliant

with the industrial standards and approvals, covering operating

temperature, power input voltage, surge, ESD and vibration. The AWK-

5222 is rugged enough to help you establish the most robust wireless

connection for critical industrial wireless applications.

Redundancy to Increase System Reliability

• Dual DC power inputs and PoE

• Dual-radio design with 2.4 and/or 5 GHz dual-band operation for

redundant WLAN connections

• Redundant roaming for fast and stable handoff

• Ethernet redundancy via RSTP

Speciﬁcations for Industrial-grade Applications

• Industrial-grade QoS and VLAN for efﬁcient data trafﬁc management

• Long-distance wireless transmission over 10 km

• Integrated DI/DO for on-site monitoring and warnings

• Signal strength LEDs for easy deployment and antenna alignment

Introduction

Dual RF

Wireless Redundancy

Dual RF

Wireless Redundancy

› IEEE 802.11a/b/g compliant

› Dual-radio design for 2.4 GHz and/or 5 GHz RF bands

› Supports client-based Turbo Roaming and redundant roaming

› -40 to 75°C operating temperature range (T models)

WLAN Interface

Standards:

IEEE 802.11a/b/g for Wireless LAN

IEEE 802.11i for Wireless Security

IEEE 802.3 for 10BaseT(X)

IEEE 802.3u for 100BaseT(X)

IEEE 802.3af for Power-over-Ethernet

IEEE 802.1D for Spanning Tree Protocol

IEEE 802.1w for Rapid STP

IEEE 802.1Q for VLAN

Spread Spectrum and Modulation (typical):

•DSSSwithDBPSK,DQPSK,CCK

•OFDMwithBPSK,QPSK,16QAM,64QAM

64QAM@54Mbps,16QAM@24/36Mbps,QPSK@12/18Mbps,

CCK@11/5.5Mbps,DQPSK@2Mbps,DBSK@1Mbps

•802.11b:CCK@11/5.5Mbps,DQPSK@2Mbps,

DBPSK@11Mbps

•802.11a/g:64QAM@54/48Mbps,16QAM@36/24Mbps,

QPSK@18/12Mbps,BPSK@9/6Mbps

Operating Channels (central frequency):

US:

2.412to2.462GHz(11channels)

5.18 to 5.24 GHz (4 channels)

EU:

2.412 to 2.472 GHz (13 channels)

5.18 to 5.24 GHz (4 channels)

JP:

2.412 to 2.472 GHz (13 channels, OFDM)

2.412 to 2.484 GHz (14 channels, DSSS)

5.18 to 5.24 GHz (4 channels for W52)

Security:

•SSIDbroadcastenable/disable

•FirewallforMAC/IP/Protocol/Port-basedltering

•64-bitand128-bitWEPencryption,WPA/WPA2Personaland

Enterprise (IEEE 802.1X/RADIUS, TKIP and AES)

Transmission Rates:

802.11b:1,2,5.5,11Mbps

802.11a/g:6,9,12,18,24,36,48,54Mbps

TX Transmit Power:

802.11b:

Typ.23±1.5dBm@1to11Mbps

802.11g:

Typ.20±1.5dBm@6to24Mbps,Typ.19±1.5dBm@36Mbps,Typ.

18±1.5dBm@48Mbps,Typ.17±1.5dBm@54Mbps

802.11a:

Typ.18±1.5dBm@6to24Mbps,Typ.16±1.5dBm@36to48Mbps,

Typ.15±1.5dBm@54Mbps
