2
Industrial Wireless LAN Solutions
©MoxaInc.AllRightsReserved.UpdatedMar.16,2015.Specicationssubjecttochangewithoutnotice.Pleasevisitourwebsiteforthemostup-to-dateproductinformation.
Ordering Information
Dimensions
Unit:mm(inch)
Front View Rear View Side View Top & Bottom Views
62 (2.44) 105 (4.13)
135 (5.31)
Available Models
AWK-5222-US: IEEE 802.11a/b/g dual-radio wireless AP/bridge/client, US band
AWK-5222-US-T: IEEE 802.11a/b/g dual-radio wireless AP/bridge/client, US band, -40 to 75°C
operating temperature
AWK-5222- EU: IEEE 802.11a/b/g dual-radio wireless AP/bridge/client, EU band
AWK-5222- EU -T: IEEE 802.11a/b/g dual-radio wireless AP/bridge/client, EU band, -40 to 75°C
operating temperature
AWK-5222-JP: IEEE 802.11a/b/g dual-radio wireless AP/bridge/client, JP band
AWK-5222-JP-T: IEEE 802.11a/b/g dual-radio wireless AP/bridge/client, JP band, -40 to 75°C
operating temperature
Note:PleasevisitMoxa’swebsiteforacompletelistofoptionalwirelessaccessoriesandantennasavailablefor
Moxa’s wireless products.
Package Checklist
• AWK-5222 wireless AP/bridge/client
• DIN-rail kit
• 2 plastic RJ45 protective caps for LAN &
Console ports
• Cable holder with one screw
• Documentation and software CD
• Quick installation guide (printed)
• Warranty card
Note:2dual-bandomni-directionalantennas
are included with the AWK-5222 model.
RX Sensitivity:
802.11b:
-97dBm@1Mbps,-94dBm@2Mbps,-92dBm@5.5Mbps,-90
dBm@11Mbps
802.11g:
-93dBm@6Mbps,-91dBm@9Mbps,-90dBm@12Mbps,-88
dBm@18Mbps,-84dBm@24Mbps,-80dBm@36Mbps,-76dBm
@48Mbps,-74dBm@54Mbps
802.11a:
-90dBm@6Mbps,-89dBm@9Mbps,-89dBm@12Mbps,-85
dBm@18Mbps,-83dBm@24Mbps,-79dBm@36Mbps,-75dBm
@48Mbps,-74dBm@54Mbps
Protocol Support
General Protocols: Proxy ARP, DNS, HTTP, HTTPS, IP, ICMP, SNTP,
TCP, UDP, RADIUS, SNMP, PPPoE, DHCP
AP-only Protocols: ARP, BOOTP, DHCP, STP/RSTP (IEEE 802.1D/w)
Interface
Default Antennas: 2 dual-band omni-directional antennas, 2 dBi,
RP-SMA (male)
Connector for External Antennas: RP-SMA (female)
RJ45Ports:2,10/100BaseT(X),autonegotiationspeed,F/Hduplex
mode, and auto MDI/MDI-X connection
Console Port: RS-232 (RJ45-type)
Reset: Present
LED Indicators: PWR1, PWR2, PoE, FAULT, STATE, WLAN1, WLAN2,
10M, 100M
Alarm Contact (digital output): 1 relay output with current carrying
capacityof1A@24VDC
Digital Inputs: 2 electrically isolated inputs
•+13to+30Vforstate“1”
•+3to-30Vforstate“0”
•Max.inputcurrent:8mA
Physical Characteristics
Housing: Metal, IP30 protection
Weight: 1.1 kg
Dimensions:62x135x105mm(2.4x5.3x4.1in)
Installation: DIN-Rail mounting (standard), Wall mounting (optional)
Environmental Limits
Operating Temperature:
StandardModels:-25to60°C(-13to140°F)
WideTemp.Models:-40to75°C(-40to167°F)
Storage Temperature: -40 to 85°C (-40 to 185°F)
Ambient Relative Humidity:5%to95%(non-condensing)
Power Requirements
Input Voltage: 12 to 48 VDC, redundant dual DC power inputs or 48
VDC Power-over-Ethernet (IEEE 802.3af compliant)
Connector: 10-pin removable terminal block
Power Consumption: 12 to 48 VDC, 800 mA (max.)
Reverse Polarity Protection: Present
Standards and Certifications
Safety:UL60950-1,EN60950-1
EMC:EN301489-1/17,FCCPart15SubpartB,EN55022/55024,
IEC61000-6-2/4
Radio:EN300328,EN301893,FCCIDSLE-WAPA003
Note:PleasecheckMoxa’swebsiteforthemostup-to-datecerticationstatus.
Reliability
MTBF (mean time between failures):291,367hrs
Warranty
Warranty Period: 5 years
Details: See www.moxa.com/warranty
