- 6 -

NOTE

Before tightening the screws into the wall, make sure the screw

head and shank size are suitable by inserting the screw into one

of the keyhole-shaped apertures of the wall mounting plates.

Do not screw the screws in completely—leave about 2 mm to allow room

for sliding the wall mount panel between the wall and the screws.

STEP 3:

Once the screws are fixed in the wall, insert the four screw heads through

the large parts of the keyhole-shaped apertures, and then slide the

IEX-402-SHDSL downwards, as indicated. Tighten the four screws for

added stability.

Wiring Requirement

ATTENTI

Safety First!

Be sure to disconnect the power cord before installing and/or

wiring your Moxa Ethernet Extender.

Calculate the maximum possible current in each power wire and

common wire. Observe all electrical codes dictating the

maximum current allowab

le for each wire size.

If the current goes above the maximum ratings, the wiring could

overheat, causing serious damage to your equipment

Be sure to read and follow these important guidelines:

• Use separate paths to route wiring for power and devices. If power

wiring and device wiring paths must cross, make sure the wires are

perpendicular at the intersection point.

NOTE: Do not run signal or communications wiring and power wiring

through the same wire conduit. To avoid interference, wires with

different signal characteristics should be routed separately.

• Use the type of signal transmitted through a wire to determine which

wires should be kept separate. The rule of thumb is that wiring that

shares similar electrical characteristics can be bundled together.

• Keep input wiring and output wiring separate.

• When necessary, you should label the wiring to all devices in the

system.

Grounding the Ethernet Extender

Grounding and wire routing help limit the effects of noise due to

electromagnetic interference (EMI). Run the ground connection from the

ground screw to the grounding surface prior to connecting devices.

ATTENTION

This product is intended to be mounted to a well

-grounded

mounting surface, such as a metal panel.
