Multiport Serial Boards
1
www.moxa.com
POS-104UL
4-port RS-232 Universal PCI boards with power over serial
The POS-104UL is a smart, 4-port Universal PCI serial board designed
for POS and ATM applications and for use by industrial automation
system manufacturers and system integrators. The POS-104UL is
compatible with all major operating systems. In addition, each of the 4
RS-232 serial ports supports data rates up to 921.6 kbps and provides
full modem control signals to ensure compatibility with a wide range
of serial peripherals. The POS-104UL supplies 5 or 12 volts of power
to each serial port, and it works with both 3.3 V and 5 V PCI buses,
making it suitable for installation in most PC servers.
Introduction
Specifications
› Over 800 kbps data throughput, for top performance
› Power options for each port: 5 V (output), 12 V (output), and RI
(input)
› Serial port power from bus or power supply
› 921.6 kbps maximum baudrate for super fast data transmission
› 128-byte FIFO and on-chip H/W, S/W flow control
› Compatible with 3.3/5 V PCI and PCI-X
› Low profile board, suitable for compact-sized PCs
› Drivers provided for a broad selection of operating systems,
including the latest Windows and Linux
› Wide temperature model available for -40 to 85°C environments
Hardware
Comm. Controller: MU860 (16C550C compatible)
Bus: 32-bit Universal PCI
Connector: DB44 female
Serial Interface
Number of Ports: 4
Serial Standards: RS-232
Max. No. of Boards per PC: 4
Performance
Baudrate: 50 bps to 921.6 kbps
Serial Communication Parameters
Data Bits: 5, 6, 7, 8
Stop Bits: 1, 1.5, 2
Parity: None, Even, Odd, Space, Mark
Flow Control: RTS/CTS, XON/XOFF
Serial Signals
RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND, RI (optional)
Physical Characteristics
Dimensions: 64.4 x 120 mm (2.53 x 4.72 in)
Driver Support
Windows: Windows 95/98/ME/NT/2000, Windows XP/2003/
Vista/2008/7/8/8.1/10 (x86/x64), Windows 2008 R2/2012/2012 R2
(x64), DOS, Windows Embedded CE 5.0/6.0, Windows XP Embedded
Linux: Linux 2.4.x, 2.6.x, 3.x
Unix-like Systems: QNX 6, SCO OpenServer, UnixWare 7, Solaris 10,
FreeBSD
Note: Please refer to Moxa’s website for the latest driver support information.
Environmental Limits
Operating Temperature:
Standard Models: 0 to 55°C (32 to 131°F)
Wide Temp. Models: -40 to 85°C (-40 to 185°F)
Storage Temperature: -40 to 85°C (-40 to 185°F)
Ambient Relative Humidity: 5 to 95% (non-condensing)
Standards and Certifications
EMC: EN 61000-6-2/6-4
EMI: CISPR 22, FCC Part 15B Class B
EMS:
IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m
IEC 61000-4-4 EFT: Power: 2 kV; Signal: 1 kV
IEC 61000-4-5 Surge: Power: 2 kV
IEC 61000-4-6 CS: 150 kHz to 80 MHz: 10 V/m; Signal: 10 V/m
IEC 61000-4-8 PFMF
IEC 61000-4-11
MTBF (mean time between failures)
Time: 2,124,022 hrs
Standard: Telcordia (Bellcore) TR/SR
Power Requirements
Input Current: 145 mA @ 5 VDC
Warranty
Warranty Period: 5 years
Details: See www.moxa.com/warranty
