Pioneer A-30-K [14/57] Isn t f_mute set to h isn t the sound muted
![Pioneer A-10-K [14/57] Isn t f_mute set to h isn t the sound muted](/views2/1199331/page14/bge.png)
14
A-30-K
1
2 3 4
A
B
C
D
E
F
1
2 3 4
A-30 ONLY
B
Yes
Yes
No
Yes
No
No
No
No
Yes
Yes Yes Yes
No
Isn't the
symptom changed by
DIRECT ON/OFF ?
Only DIRECT OFF
is not output
Solder failure of R503, R514
Connection failure between
CN41 and BN41
IC51, IC52 failure
Is there
a signal at J208 and
J209 (RY21 output) ?
PURE DIRECT control signal circuit
failure (Q203, Q204, R259, R261)
Connection failure between CY93 and CX93
RY21 failure
Is there
a signal at J215
(RY22 output) ?
P_AMP DIRECT control signal circuit
failure (Q205, Q206, R260, R262)
Connection failure between CY93 and CX93
RY22 failure
Is there a
signal at power amplifier
input (R301, R302) ?
Isn't F_MUTE
set to "H" ?
(Isn't the sound
muted ?)
Is ±15V of
MUTE circuit properly
supplied ?
Solder failure of R301,
R302, C301, C302
Reset MUTE
Solder failure of IC11:
44 pin
F_MUTE control signal
circuit failure (Q207-Q212)
Connection failure
between CY93 and CX93
D250 failure
Solder failure of R275
