V2101 Hardware Hardware Introduction

2-3

LED Indicators

LED Name LED Color LED Function

Power

Green Power is on and functioning normally

Off

No power is getting to the system: power is off or has failed.

Storage

Yellow SD card is detected

Off SD card is not detected

LAN

Green 100 Mbps Ethernet mode

Yellow 1000 Mbps (Gigabit) Ethernet mode

Off No activity or 10 Mbps Ethernet mode

Tx1, Tx2

(P1-P2)

Green Serial ports P1-P2 transmitting data

Off Serial ports P1-P2 not transmitting data

Rx1, Rx2

(P1-P2)

Yellow Serial ports P1-P2 receiving data

Off Serial ports P1-P2 not receiving data

Reset Button

Press the Reset Button on the front panel of the V2101 for a soft reboot of the system. The Ready LED will

blink on and off for the first 5 seconds, and then maintain a steady glow once the system has completed

rebooting.

The V2101 does not support a Reset to Default function.

Real Time Clock

The embedded computer’s real-time clock is powered by a lithium battery. We strongly recommend that you do

NOT replace the lithium battery on your own. If the battery needs to be changed, please contact the Moxa RMA

service team.

ATTENTION

There is a risk of explos

ion if an incompatible battery is used to replace the lithium clock battery

. To avoid this

potential danger, always be sure to use the correct type of battery. Contact the Moxa RMA service team if you

need to replace your battery.

Please d

ispose of used batteries according to best practices for hazardous and toxic materials.
