DA-681 Series WinCE User’s Manual Software Configuration

Resetting Your DA-681-CE Computer

Cold-Start

Disconnect and then reconnect the power. The computer will reboot itself right away.

Warm-Start

To reboot the computer when the power is on, push the reset button on the rear panel and then

release it within 1 second. The computer will reboot itself.

Reset to Factory Default

If the computer is not working properly and you want to load factory default settings, press “8”

when the “Windows Embedded CE 6.0” loader image is displayed during the first 4 or 5 seconds

of the power on sequence. The optional prompts are described step by step as follows:

Step1: Scan Disk (Automatically).

Windows CE 6.0 supports the FAT file system. Sometimes, due to unstable power or

application issues, the files, directories, or FAT table could be damaged. The “Scandisk”

routine will help you scan the file system and auto-fixed file or directory corruption

problems.

ATTENTION

After running Scan Disk, you might find some files named “FILE00xx.chk,” which means some

files or directories were damaged and hves been fixed.

Step2: Reset to Default? (Y/N).

Type “Y” to load factory default settings and the configuration file.

Step3: Clean all files and directories? (Y/N)

You can clear all garbage files and directories by selecting this option.

Step4 Proceed? (Y/N)

Type “Y” to start the Reset to Factory Defaults Procedure. After the factory default

configuration has been loaded, the system will reboot automatically.

Changing the Network Settings

The DA-681-CE computer comes with six network interfaces. The default IP addresses and

netmasks of the network interfaces are as follows:

Default IP Address Netmask

LAN 1

192.168.3.127 255.255.255.0

LAN 2

192.168.4.127 255.255.255.0

LAN 3

192.168.5.127 255.255.255.0

LAN 4

192.168.6.127 255.255.255.0

LAN 5

192.168.7.127 255.255.255.0

LAN 6

192.168.8.127 255.255.255.0

2-3
