Moxa UC-8410-CE Технические характеристики онлайн
1
www.moxa.com
info@moxa.com
Compact/Fanless Computers
UC-8410/8416/8418 Series
RISC ready-to-run embedded computers with 8 serial ports,
3 LANs, DIO, 8 switch ports, 2 CAN ports, USB, CompactFlash
Overview
Appearance
The UC-8410/8416/8418 Series embedded computers come with
8 RS-232/422/485 serial ports, 3 Ethernet ports, 2 CAN ports, 8
Ethernet ports, 12 digital input channels, 12 digital output channels, a
CompactFlash socket, and 2 USB 2.0 hosts.
The computers use the Intel XScale IXP435 533 MHz RISC CPU. This
powerful computing engine supports several useful communication
functions, but will not generate too much heat. The built-in 16 MB NOR
Flash ROM and 256 MB SDRAM give you enough memory to run your
application software directly on the UC-8418, and the 32 MB NAND
Flash can be used to provide additional data storage. Moreover, the
256 KB SRAM offers a better data retention mechanism for avoiding
data loss. These computers come with various communication
interaces, such as serial ports, Ethernet ports, CAN ports, and digital
input/output channels, making them ideal as a communication
platform for industrial applications that require network and device
communications.
The UC-8410/8416/8418 Series comes with the Linux 2.6 or Windows
CE 6.0 platform pre-installed to provide an open software operating
system for software program development. Software written for a
desktop PC can be easily ported to the UC-8410/8416/8418 Series
platform by using a common compiler, without needing to modify the
code. This makes the these computers an optimal solution for use with
industrial applications, but with minimal cost and effort.
In addition to the standard model, a -40 to 75°C wide temperature
model is also available for harsh industrial environments.
Front View Rear View
UC-8410
› Intel XScale IXP435 533 MHz processor
› 8 RS-232/422/485 serial ports
› 2 CANbus ports (UC-8418)
› 8 unmanaged switch ports (UC-8416)
› 12 digital input and 12 digital output channels (UC-8418)
› 3 10/100 Mbps Ethernet ports
› 2 USB 2.0 hosts for mass storage devices
› Supports IPv6 function (Linux model only)
› DIN-Rail or wall mount installation
› Robust, fanless design
› -40 to 75°C wide temperature model available
› Ready-to-run Embedded Linux or Windows CE 6.0
Serial Port x 8, RJ45
(RS-232/422/485)
USB 2.0 Host x 2
Reset Button
10/100 Mbps
Ethernet x 3
DI Channel x 4
DO Channel x 4
Power Input
12 to 48 VDC
LED Indicators
(Power, SRAM Battery
Ready, Storage)
