Compact/Fanless Computers
Software Specifications
Dimensions:
• UC-8410: 200 x 37 x 120 mm (7.87 x 1.46 x 4.72 in)
• UC-8416/8418: 200 x 57 x 120 mm (7.87 x 2.24 x 4.72 in)
Mounting: DIN-Rail, wall
Environmental Limits
Operating Temperature:
Standard Models: -10 to 60°C (14 to 140°F)
Wide Temp. Models: -40 to 75°C (-40 to 167°F)
Storage Temperature:
Standard Models: -20 to 75°C (-4 to 167°F)
Wide Temp. Models: -40 to 85°C (-40 to 185°F)
Ambient Relative Humidity: 5 to 95% (non-condensing)
Anti-vibration: 2 g rms @ IEC-68-2-34, random wave, 5-500 Hz, 1 hr
per axis
Anti-shock: 20 g @ IEC-68-2-27, half sine wave, 11 ms
Power Requirements
Input Voltage: 12 to 48 VDC (3-pin terminal block)
Power Consumption: 15 W
• 310 mA @ 48 VDC
• 625 mA @ 24 VDC
• 1350 mA @ 12 VDC
Standards and Certifications
Safety: UL 60950-1, EN 60950-1, CCC (GB9254, GB17625.1)
EMC: EN 55022 Class B, EN 55024-4-2, EN 55024-4-3, EN 55024-4-4,
FCC Part 15 Subpart B Class B
Reliability
Alert Tools: Built-in buzzer and RTC (real-time clock)
Automatic Reboot Trigger: Built-in WDT (watchdog timer)
MTBF (mean time between failures):
• UC-8410: 171,369 hrs
• UC-8416: 156,942 hrs
• UC-8418: 149,140 hrs
Warranty
Warranty Period: 5 years
Details: See www.moxa.com/warranty
Note: The Hardware Specications apply to the embedded computer unit itself,
but not to accessories. In particular, the wide temperature specication does not
apply to accessories such as the power adaptor and cables.
Linux
OS: Linux 3.8.13
File System: JFFS2, NFS, Ext2, Ext3
Internet Protocol Suite: TCP, UDP, IPv4, IPv6, SNMPv1, ICMP, ARP,
HTTP, CHAP, PAP, DHCP, NTP, NFS, SMTP, Telnet, FTP, TFTP, PPP,
PPPoE
Internet Security: OpenVPN, iptables rewall
Web Server (Apache): Allows you to create and manage web sites;
supports PHP and XML
Terminal Server (SSH): Provides secure encrypted communications
between two un-trusted hosts over an insecure network
Dial-up Networking: PPP Daemon for Linux that allows Unix machines
to connect to the Internet through dialup lines, using the PPP protocol,
as a PPP server or client. Works with ‘chat’, ‘dip’, and ‘diald’, among
(many) others. Supports IP, TCP, UDP, and (for Linux) IPX (Novell).
Watchdog: Features a hardware function to trigger system reset in a
user specied time interval (Moxa API provided)
Application Development Software:
• Moxa API Library (Watchdog timer, Moxa serial I/O control, Moxa DI/
DO API)
• GNU C/C++ cross-compiler
• GNU C library
• GDB source-level debugging server
Software Protection: Encryption tool for user executable les (based
on patented Moxa technology)
Windows Embedded CE 6.0
OS: Windows Embedded CE 6.0
File System: FAT
Internet Protocol Suite: TCP, UDP, IPv4, IPv6, SNMPv2, ICMP, IGMP,
ARP, HTTP, CHAP, PAP, SSL, DHCP, SNTP, SMTP, Telnet, FTP, PPP
Web Server (WinCE IIS): Supports ASP, ISAPI Secure Socket Layer
(SSL 2/3) and Transport Layer Security (TLS/SSL 3.1) public
key-based protocols, and Web Administration ISAPI Extensions
Dial-up Networking: Supports RAS client API and PPP, Extensible
Authentication Protocol (EAP), and RAS scripting
Watchdog: Features a hardware function to trigger system reset in a
user specied time interval. (Moxa API provided)
Application Development Software:
• Moxa WinCE 6.0 SDK
• Moxa API Library
• C Libraries and Run-times
• Component Services (COM and DCOM)
• Microsoft® .NET Compact Framework 3.5
• XML, including DOM, XQL, XPATH, XSLT, SAX, SAX2
• SOAP Toolkit Client
• Winsock 2.2
