UC-8410/8416/8418/8430 Getting Started
2-2
Powering on the UC-8410/8416/8418/8430
Connect the SG wire to the Shielded Contact located in the upper left corner of the UC-8410/8416/8418/8430,
and then power on the computer by connecting it to the power adaptor. It takes about 30 to 60 seconds for the
system to boot up. Once the system is ready, the Ready LED will light up.
ATTENTION
After connecting the UC-8410/8416/8418/8430/8430 to the power supply, it
will take about 16 seconds for
the operating system to boot up. The green Ready LED will not turn on until the operating system is ready.
Connecting the
UC-8410/8416/8418/8430/8430 to a PC
There are two ways to connect the UC-8410/8416/8418/8430/8430 to a PC: directly through the serial console
port, or by Telnet over the network. For the UC-8430, you can connect the display with the display cable. Once
you turn on the power, you will be able to access the computer and conduct additional configurations.
Serial Console
The serial console port gives users a convenient way of connecting to the UC-8410/8416/8418/8430’s console
utility. This method is particularly useful when using the computer for the first time. The signal is transmitted
over a direct serial connection, so you do not need to know either of its 3 IP addresses in order to connect to
the UC-8410/8416/8418/8430.
Use the serial console port settings shown below.
Baudrate 115200 bps
Parity None
Data bits 8
Stop bits 1
Flow Control None
Terminal VT100
Once the connection is established, you can start using UC-8410/8416/8418/8430.
Telnet Console
If you know at least one of the IP addresses and netmasks, you can use Telnet to connect to the
UC-8410/8416/8418/8430’s console utility. The default IP address and Netmask for each of the ports are given
below:
Default IP Address Netmask
LAN 1* 192.168.3.127 255.255.255.0
LAN 2 192.168.4.127 255.255.255.0
LAN 3 192.168.5.127 255.255.255.0
*Please note that the LAN1 of the UC-8430 uses DHCP for both IP Address and Netmask.
Use a cross-over Ethernet cable to connect directly from your PC to the UC-8410/8416/8418/8430. You should
first modify your PC’s IP address and netmask so that your PC is on the same subnet as one of the
UC-8410/8416/8418/8430’s LAN ports. For example, if you connect to LAN 1, you can set your PC’s IP address
to 192.168.3.126 and netmask to 255.255.255.0. If you connect to LAN 2, you can set your PC’s IP address to
192.168.4.126 and netmask to 255.255.255.0.
