IA260 Hardware User’s Manual Hardware Connection Description
ATTENTION
The IA260 does not support CompactFlash hot swap and PnP (Plug and Play) function. It is
necessary to remove power source first before inserting or removing the CompactFlash card.
USB Hosts
The IA260 provides 2 USB 2.0 full speed hosts (OHCI), type A connectors, which support a
keyboard or mouse, as well as an external flash disk for storing large amounts of data.
3-8
