Moxa IA261-I-T-LX [6/24] Product features
![Moxa IA261-I-T-LX [6/24] Product features](/views2/1199954/page6/bg6.png)
IA260 Hardware User’s Manual Overview
Both models are shipped with the following items:
y 1 IA260 Embedded Computer
y Wall-Mounting Kit
y DIN-Rail Mounting Kit (attach to the product’s casing)
y Quick Installation Guide
y Document & Software CD
y Ethernet Cable: RJ45 to RJ45 cross-over cable, 100 cm
y CB
L-4P
INDB9F-100: 4-pin header to DB9 female console port cable, 100 cm
y Universal Power Adaptor (includes terminal block to power jack converter)
y Product Warranty Statement
NOTE: Notify your sales representative if any of the above items are missing or damaged.
Product Features
y Cirrus Logic EP9315 ARM9 CPU, 200 MHz
y 128 MB RAM on-board, 32 MB Flash Disk
y VGA interface for field site monitoring
y 4 RS-232/422/485 serial ports
y Dual 10/100 Mbps Ethernet ports for network redundancy
y 8+8 DI/DO channels
y 12 to 48VDC power input design
y Supports CF socket and USB 2.0 Host
y Ready-to-Run WinCE 6.0 or Linux platform
y -40 to 75°C wide temperature model available
Product Hardware Specifications
Computer
CPU
Cirrus Logic EP9315 ARM9 CPU, 200 MHz
DRAM
128 MB onboard
Flash
32 MB onboard
Storage Expansion
CompactFlash socket
USB
USB Host x 2 compliant to USB 2.0 (OHCI), Type A connector
Reset Button
Supports “Reset to Factory Default”
OS (pre-installed)
WinCE 6.0 or Linux
LAN Interface
Ethernet
Auto-sensing 10/100 Mbps x 2, RJ45 connectors
Magnetic Isolation
Protection
1.5 KV built-in
Serial Interface
Number of Ports
4
Serial Standards
RS-232/422/485, software-selectable
Connectors
DB9 male
1-3
