IA260 Hardware User’s Manual Overview
Environmental Limits
Operating Temperature
Standard Models: -10 to 60°C (14 to 140°F)
Wide Temp. Models: -40 to 75°C (-40 to 167°F)
Operating Humidity
5 to 95% RH
Storage Temperature
Standard Models: -20 to 80°C (-4 to 176°F)
Wide Temp. Models: -40 to 85°C (-40 to 185°F)
Anti-Vibration 2 g rms @ IEC-68-2-34, random wave, 5-500 Hz, 1 hr/axis
Anti-Shock 20 g @ IEC-68-2-27, half sine wave, 11 ms
Power Requirements
Input Voltage
12 to 48 VDC (3-pin terminal block)
Power Consumption
480 mA @ 12 VDC (with no load on USB ports)
900 mA @ 12 VDC (with load on 2 USB ports)
Regulatory Approvals
EMC
CE (EN55022 Class A, EN61000-3-2 Class A, EN61000-3-3,
EN55024), FCC (Part 15 Subpart B, CISPR 22 Class A), CCC
(GB9254, GB 17625.1)
Safety
UL/cUL (UL60950-1, CSA C22.2 No. 60950-1-03), LVD
(EN60950-1), CCC (GB4943)
Automatic Reboot
Trigger
Built-in WDT (watchdog timer)
Warranty
5 years
Please note that the Hardware Specifications apply to the embedded computer unit itself, but not to
accessories. In particular, the wide temperature specification does not apply to accessories such as
the power adaptor and cables.
1-5
